Streaming in Legate#

Streaming is a new execution mode in the Legate runtime that (under certain conditions) allows a series of operations to execute in batches, ultimately allowing the same series of operations to run using less memory. Under standard execution mode, if a task produces a result for a subsequent task that consumes it, the consumer task cannot start until the producer task has finished execution, due to the data dependency. With Streaming, the data dependencies are applied at a finer level, where a producer task is submitted in batches, where each batch operates over a subset of data, which produces partial results and allows, under certain conditions, a subsequent consumer task to start early and consume those results.

This typically results in a lower memory footprint because the temporary data created during the execution is typically smaller in size, proportional to the batch size, and can be discarded after use. For example, suppose that we wanted to load two very large vectors (x and y) from disk, add them together, and store the result in a third vector (r), i.e. r = x[:] + y[:]. Under streaming, we can load a batch of x, and a batch of y to produce a batch of r and then discard the x and y batches.

This feature is experimental and does not yet support all use-cases. Invalid use may lead to exceptions, hangs, or outright crashes. Upcoming releases will focus on rounding out this feature, adding safety checks etc.

import cupynumeric as np

A = np.ones(1024 * 1024) # FILL Task
A = A + 1 # INC Task
s = A.sum() # SUM Task

We will describe the Streaming schedule with an example code shown above. The code consists of three tasks (FILL, INC, SUM) that operate on the same array. Figure (a) below shows the execution without Streaming, where a task like FILL is scheduled on the entire array. The dependent task (INC) can only start executing when FILL has completed its execution. With Streaming, shown in Figure (b), the Legate runtime will decompose the array into smaller batches and schedule a separate FILL task for each batch, followed by INC and SUM tasks similarly. This is a valid schedule as long as the consumer task, e.g, INC, depends only on one batch of the data that was produced by the producer task FILL. Therefore, Streaming places some restrictions on tasks and their dependencies, which we discuss later on.

../../_images/streaming_example_1.png

Streaming Syntax#

Streaming in Legate is enabled inside a Scope by setting the ParallelPolicy member with the streaming flag set to true. Additionally, the users can optionally set the over_decompose_factor, which decides the number of batches. Without Streaming, Legate partitions data such that each processor gets one partition of the data. With the ‘over_decompose_factor’, the amount of partitions is increased by this factor. For example, on 8 processors, with over_decompose_factor=4, a 1MB array will be partitioned into 32 partitions of 32KB each. Therefore, over_decompose_factor determines the batch size. The snippets below show how the Scope can be used with ParallelPolicy to enable Streaming inside the scope.

from legate.core import ParallelPolicy, Scope

pp = ParallelPolicy(streaming=True, over_decompose_factor=4)
with Scope(paralle_policy=pp):
    # submit task 1
    # submit task 2
    # ...
{
  auto pp = legate::ParallelPolicy{}
               .with_streaming(true)
               .with_over_decompose_factor(4);
  auto s = legate::Scope{}.with_parallel_policy(pp);
  // submit task 1
  // submit task 2
  // ...
}

Streaming Restrictions#

For Streaming to be valid, the partial execution of tasks must respect the dependencies of the original program order, i.e., without streaming. This results in restrictions on what task patterns are permitted inside a Streaming Scope. The restrictions themselves are hard to precisely describe because a user generally does not have visibility into the partitioning and scheduling decisions made by the Legate Runtime. In this section, we first describe the theory that motivates these restrictions and then provide a list of concrete program patterns in Legate that will likely violate the program dependencies inside a Streaming Scope. In the future, Legate will include a checker for Streaming execution to provide feedback to users when streaming execution cannot be performed.

Theory: For a Streaming Scope to be valid, i.e., respect the original program order, the following conditions must hold:

  1. Each task must launch the same number of workers. This is a limitation of current implementation and should go away in the future. 2. Each sub-task must read and/or update at most one partition of a store. If a task depends on more than one partition of a store that is updated by a preceding task (in the program order), the streaming schedule is not valid for such a program.

  1. Partitioning of a store must not change from one task to another task. Changing the partitioning may violate the aforementioned condition of depending on at most one partition of the store.

  1. Reductions with associative operators are an exception to the above rule as long as a later task does not read or write the source or results of the reduction.

Practice: Here, we describe a set of guidelines that a user should follow for tasks inside a Streaming Scope. These guidelines may be imprecise and overly restrictive in some cases

  1. Manipulating data of different shapes: The shape of the data determines the shape of the parallel launch for the task. Using data of different shapes may result in violating the condition 1 above. 2. Using Partitioning Constraints: Certain partitioning constraints may cause a task to depend on more than one partition of the previous task. We discuss each kind separately:

  1. Align: Align is OK to use as long as one variable (referring to a store or array) is not aligned with variables of different shapes simultaneously. For example, aligning the same data by rows and columns in different tasks violates condition 2 above. 2. Scale: Similar to Align 3. Broadcast: OK to use as long as the variable being broadcast is never partitioned for any tasks in the Streaming Scope. 4. Bloat: Should not be used unless the variable is read-only, as it allows overlapping partitions. 5. Image: Should not be used as the partition contents are data dependent and may violate conditions 1 and 2 above.

  1. Reading or over-writing the results of a reduction operation: If a task attempts to read or write the results of a reduction, this will result in a race condition because the reduction has not completed until all batches have been executed. Therefore, reduction results should be read outside the Streaming Scope.
